Thunderbolt 4 Monitor Compatibility — 4K 60Hz, Daisy Chain & Docking

Thunderbolt 4 is the gold standard for laptop video connectivity. Every Thunderbolt 4 port is guaranteed to support two 4K monitors simultaneously at 60Hz without external docks—something no other laptop port type can promise. This means a MacBook Pro, Dell XPS 13/15, or Lenovo ThinkPad X1 with TB4 can drive professional dual-monitor productivity setups straight out of the box. But Thunderbolt 4 does more than just video: it supports daisy chaining (connecting monitors sequentially), delivers up to 100W of power, and integrates seamlessly with Thunderbolt docks that expand your laptop’s capabilities. This guide explains what TB4 actually does for monitors, how to take advantage of daisy chaining, and which monitors are worth the premium price. For practical dual-monitor setup guidance, see our dual 4K monitor setup guide.

Thunderbolt 4: The Specification

Thunderbolt 4 is the next evolution of Thunderbolt 3. Both offer 40 Gbps bandwidth, but TB4 guarantees certain capabilities that TB3 left optional. The key guarantee: every TB4 port must support DisplayPort (including dual 4K displays) and USB 3 simultaneously.

TB4 Guarantees (Per Port)

• Dual 4K at 60Hz: Two 4K monitors over a single TB4 port, guaranteed. This is legally mandated in the TB4 spec.
• 40 Gbps bandwidth: Enough for video, USB, and power delivery simultaneously.
• 100W power delivery: Charge most laptops, even 16-inch models, through the monitor or dock.
• DisplayPort 1.4 compatibility: Works with any DP monitor, adapter, or dock.
• USB 3.2 Gen 2 (up to 20 Gbps data): Transfer files at high speed.
• Daisy chaining support: Connect monitors sequentially if they support Thunderbolt daisy chaining (rare).

Thunderbolt 3 vs. Thunderbolt 4: What Changed?

Thunderbolt 3 (found on older MacBook Pro, Dell XPS, etc.) has 40 Gbps bandwidth but didn’t guarantee dual display support. Some TB3 implementations could only drive one 4K monitor. Thunderbolt 4 removed this ambiguity: every TB4 port can drive two 4K displays, full stop.

For practical purposes, modern Thunderbolt 3 laptops (2018 and newer) usually support dual 4K anyway, but TB4 is the legal guarantee.

Dual 4K Monitor Setup: The TB4 Advantage

This is TB4’s headline feature. Two separate 4K monitors running simultaneously on one laptop is transformative for productivity.

How It Works

Your TB4 port allocates its 40 Gbps bandwidth to two separate video streams. Each stream can push 4K at 60Hz (each stream needs ~17.6 Gbps for 4K). The math works: 17.6 × 2 = 35.2 Gbps, leaving headroom.

This is different from USB-C DP Alt Mode, which shares bandwidth between video and USB data. TB4 keeps them separate—video gets its full bandwidth, USB gets its own.

Setup Scenarios

Scenario 1: Two Thunderbolt Monitors + Laptop (Ideal, but rare)
Connect monitor A to TB4 port 1 and monitor B to TB4 port 2 (if your laptop has two TB4 ports). Done. Both monitors run at 4K 60Hz natively. Examples: Dell XPS 13/15 with two TB4 ports.

Scenario 2: One TB4 Monitor + One DP/HDMI Monitor (Common)
Use a TB4 monitor on one TB4 port, and a standard DP/HDMI monitor on a separate HDMI/DP port (if your laptop has one). This is how MacBook Pro users often set up dual displays.

Scenario 3: TB4 Dock + Two Monitors (Most Flexible)
Connect a TB4 dock to your laptop’s TB4 port. The dock expands to two DisplayPort outputs (or HDMI + DisplayPort). Connect your two 4K monitors to the dock’s outputs. The dock manages the two video streams internally. Examples: TB4 docks on Amazon UK. For more on docking solutions, check our docking station guide.

Bandwidth Math: Why TB4 Matters

4K 60Hz over DisplayPort 1.4 requires ~17.6 Gbps. Two simultaneous 4K streams need 35.2 Gbps. TB4’s 40 Gbps just barely fits both streams with USB 3 data (which adds overhead). USB-C DP Alt Mode’s 32 Gbps can theoretically handle one 4K stream, but adding dual displays is impossible without compromising resolution or refresh rate.

This is why TB4 is superior: it’s the only laptop port type that guarantees true dual 4K native support.

Thunderbolt Daisy Chaining: The Underutilized Feature

Daisy chaining is a feature where you connect the first monitor’s TB4 output to the second monitor’s TB4 input, creating a chain. Only the first monitor connects to the laptop; the second monitor receives its signal from the first.

Pros

• Reduces the number of cables running from your laptop to the desk
• Works across multiple monitors (theoretically infinite, limited by bandwidth)
• Elegant cable management

Cons

• Very few monitors support TB4 daisy chaining. It’s optional in the TB4 spec, so most monitor manufacturers skip it.
• Older Thunderbolt displays (Cinema Display) supported daisy chaining, but modern TB4 monitors rarely do.
• If the first monitor fails, the second monitor loses signal.
• Minimal cable savings in real-world setups (one cable vs. two is negligible).

Practical Recommendation

Don’t buy a Thunderbolt monitor hoping for daisy chaining support. It’s nice in theory but rarely implemented. Use two separate TB4 monitor connections (if your laptop has them) or a TB4 dock with two DisplayPort outputs. You’ll have more options and better reliability.

Thunderbolt 4 Power Delivery: Charging Your Laptop

TB4 supports up to 100W power delivery. This means a Thunderbolt monitor or dock can charge your laptop simultaneously with displaying video.

Which Laptops Can Charge at 100W?

• MacBook Pro 14-inch and 16-inch: Need 96-140W. TB4 monitors with 100W are borderline. A TB4 dock or monitor with full 100W delivery can charge the 14-inch slowly.
• Dell XPS 13: 61W required. Any TB4 monitor with 60W+ will charge it. TB4 monitors typically provide 100W, so no issue.
• Dell XPS 15: 130W required. TB4 100W is insufficient—you still need a separate charger for fast charging.
• Dell XPS 17: 140W+ required. TB4 100W won’t keep up with heavy usage. Bring the original charger.
• Gaming laptops: Often 180W+ required. TB4 100W is supplementary only.

Practical Use: Slow Charge vs. Trickle

Even if a TB4 monitor provides less power than your laptop demands, it will still charge—just slowly. A MacBook Pro 16-inch with 100W power delivery will charge on a TB4 monitor at maybe 20-30W net (after display consumption), so you’ll lose battery during heavy work. This is acceptable for light usage (web browsing, email) but not for sustained video editing or gaming.

Solution for High-Power Laptops

If you have a large, power-hungry laptop (16-inch or gaming), use the TB4 monitor or dock for video only, and keep your original charger nearby for full-speed charging. It’s not ideal, but it’s realistic.

Thunderbolt 4 Monitors: What Exists?

TB4 monitors are expensive and rare. Most “4K monitors for laptops” are USB-C or HDMI, not Thunderbolt.

Expensive TB4 Native Monitors

LG UltraFine 27UP550-W (Thunderbolt 3, cost ~£700) – Professional colour-accurate monitor with Thunderbolt 3 (works with TB4). 27-inch, 4K, 10-bit colour, excellent for creative work.

BenQ SW2700PT-R (USB-C with DP Alt Mode, cost ~£600) – Not TB4, but TB4 ports can drive it via USB-C DP Alt Mode. 27-inch, 1440p, 10-bit, excellent colour gamut.

Apple Pro Display XDR (cost £4,999+): The only monitor designed specifically for Thunderbolt 4 Macs. 6K display, exceptional colour accuracy. Only makes sense if you’re a professional filmmaker or colorist. Overkill for general use.

Better Alternative: TB4 Dock + Standard Monitors

Rather than buying expensive TB4 monitors, buy a TB4 dock (£300-500) and connect two standard 4K HDMI or DisplayPort monitors (£200-400 each). You get dual 4K at 60Hz and more flexibility. TB4 docks on Amazon UK from brands like Lenovo, CalDigit, and OWC are proven reliable.

Which Laptops Have Thunderbolt 4?

MacBook Pro (2021 and Later)

All MacBook Pro models from 2021 onwards have Thunderbolt 4. MacBook Pro 13, 14, and 16-inch all support dual 4K or 5K displays depending on the model.

Display limits: M1/M2 13-inch MacBook Pro supports one external 6K display. 14-inch and 16-inch M1 Pro/Max support one external display at up to 6K. Newer M2/M3 14/16-inch support up to two external displays at 6K and 4K respectively (specs vary by chip).

Dell XPS 13, 14, 15, 17 (2022 and Later)

All current-generation XPS models have Thunderbolt 4. Dual 4K support is guaranteed via two TB4 ports (or TB4 port + TB4 dock).

Lenovo ThinkPad X1 Carbon (Gen 11+)

Recent ThinkPad X1 models have Thunderbolt 4. Dual 4K support via TB4 dock or dual TB4 ports.

Lenovo ThinkPad P Series (Workstations)

Professional ThinkPad P series machines have Thunderbolt 4. Perfect for dual-monitor creative setups.

ASUS ZenBook Pro and Gaming (Some Models)

Premium ASUS machines sometimes have Thunderbolt 4. Check your specific model’s spec sheet.

HP Elite Dragonfly

HP’s premium business ultrabook has Thunderbolt 4 on recent generations.

Thunderbolt 4 Docks: The Practical Alternative to TB4 Monitors

A Thunderbolt 4 dock is the best way to leverage TB4 for multi-monitor setups without buying expensive TB4 monitors.

How TB4 Docks Work

Plug one USB-C/Thunderbolt 4 cable from your laptop to the dock. The dock expands to:

• Two DisplayPort outputs (each capable of 4K 60Hz)
• HDMI output (sometimes)
• Multiple USB 3.0 or USB-C ports
• SD card readers
• Ethernet
• Audio inputs/outputs
• Power delivery (60–100W)

Top TB4 Docks

Lenovo ThinkPad Thunderbolt 3/4 Dock (£300-450) – Reliable, supports dual 4K monitors via two DisplayPort outputs. Excellent for ThinkPad users but works with any TB4 laptop.

CalDigit TS4 (£350-500) – Professional-grade TB4 dock with dual DisplayPort, excellent build quality, 96W power delivery.

OWC Thunderbolt 4 Dock (£300-450) – High-end dock with dual DisplayPort, excellent for Mac and Windows.

Dell WD19TB (£300-400) – Dell’s official TB4 dock. Works with any TB4 laptop, especially XPS models.

Total Cost for Dual 4K Setup

TB4 Dock + Two 4K Monitors Option:

• TB4 Dock: £350
• Two 4K HDMI/DP monitors: £400-600 each (£800-1200 total)
• Cables: £50
• Total: £1200-1600

Two TB4 Monitors Option (If Possible):

• Two TB4 monitors: £700-1000 each (£1400-2000 total)
• Cables: £50
• Total: £1450-2050

Winner: TB4 dock + standard monitors is cheaper and more flexible.

Frequently Asked Questions

Can I connect two 4K monitors to my Thunderbolt 4 laptop?

Yes, guaranteed. Every TB4 port supports dual 4K at 60Hz. You can use two separate TB4 monitors (if your laptop has two TB4 ports), one TB4 monitor + one HDMI/DP monitor, or a TB4 dock with two DisplayPort outputs.

Is Thunderbolt 4 better than USB-C for monitors?

For dual monitors: yes, TB4 guarantees dual 4K support. USB-C DP Alt Mode maxes out at single 4K (dual requires a dock with DisplayLink bandwidth limitations). For single monitors: USB-C is sufficient and cheaper.

Will a Thunderbolt 4 monitor charge my laptop fully?

Depends on your laptop’s power consumption. Most TB4 monitors provide 100W. MacBook Pro 14-inch and smaller laptops will charge at this rate. MacBook Pro 16-inch and large gaming laptops need more. Check your laptop’s power requirement first.

What’s the difference between Thunderbolt 3 and Thunderbolt 4 monitors?

Thunderbolt 3 monitors also support dual displays (usually), but TB4 guarantees it legally. For practical purposes, modern TB3 monitors work with TB4 laptops fine. But TB4 is the official standard for guaranteed dual 4K support.

Do Thunderbolt 4 monitors support daisy chaining?

Very few do. It’s optional in the TB4 spec, and most manufacturers don’t implement it. Don’t rely on daisy chaining—use dual TB4 ports or a dock instead.

Is a TB4 dock cheaper than TB4 monitors?

Yes. A TB4 dock (£300-500) + two standard 4K monitors (£400-600 each) is cheaper and more flexible than two TB4-native monitors (£700-1000 each). Unless you need Thunderbolt’s extra features, go with the dock.

Can I use a Thunderbolt 4 dock with non-TB4 laptops?

Thunderbolt 4 docks are backward-compatible with USB 3 and Thunderbolt 3 laptops. Performance is identical for video output. So yes, a TB4 dock works fine with older laptops—you just don’t get the full TB4 bandwidth advantage.

Do I need a special cable for Thunderbolt 4 monitors?

Yes, use official Thunderbolt 4 cables (typically included with the monitor or dock). Third-party TB4 cables work but are less reliable. For safety, use the manufacturer’s cable.
