Lenovo ThinkCentre M80q Gen 4 Compatibility & Upgrade Guide
The M80q Gen 4 is Lenovo’s excellent mid-market compact desktop, powered by Intel’s 13th Gen processors and offering DDR4-3200 memory at a more accessible price point than the DDR5-equipped M90q. It’s a superb machine for small businesses and creative professionals working within a budget. Here’s everything you need to know about upgrading it.
Quick Specs Summary
| Component | Details |
|---|---|
| Processor | Intel 13th Gen Core i5/i7 (non-vPro options) |
| RAM Type | DDR4-3200 SO-DIMM |
| RAM Slots | 2 (max 64GB) |
| Storage | M.2 2280 NVMe + 2.5″ SATA bay |
| Connectivity | Optional TB4, WiFi 6, Bluetooth 5.2 |
| Video Out | DisplayPort + HDMI (TB4 optional) |
| Typical Price | £450–£600 (inc. VAT) |
Processor—Can It Be Upgraded?
No. The CPU is soldered to the motherboard. Like all Lenovo Tiny devices, the M80q Gen 4 prioritizes compact design over modularity. However, the 13th Gen Core i5/i7 options are more than sufficient for most professional workflows short of heavy 4K video rendering.
RAM Compatibility & Upgrade Path
The M80q Gen 4 uses DDR4-3200 SO-DIMM memory in two slots, supporting up to 64GB total. Most stock configurations ship with 8GB or 16GB—definitely worth upgrading if you juggle multiple applications or do any memory-intensive work.
Important note: This is DDR4, not DDR5. Do not confuse the two—they use different physical slots and are not compatible.
| Capacity | Speed | Type | Amazon UK Link |
|---|---|---|---|
| 16GB (2x8GB) | DDR4-3200 | SODIMM | DDR4-3200 SODIMM 16GB |
| 32GB (2x16GB) | DDR4-3200 | SODIMM | DDR4-3200 SODIMM 32GB |
| 64GB (2x32GB) | DDR4-3200 | SODIMM | DDR4-3200 SODIMM 64GB |
| 8GB (2x4GB) | DDR4-3200 | SODIMM | DDR4-3200 SODIMM 8GB |
Installation: Pop the bottom panel (tool-less, naturally), insert your SODIMM at 45°, press down to lock. The whole job takes under three minutes. No screwdriver, no fuss.
Storage & Drive Compatibility
The M80q Gen 4 includes an M.2 2280 NVMe slot and a 2.5″ SATA bay. Both are user-replaceable and support high-capacity drives.
| Slot | Interface | Max Size | Compatible Products |
|---|---|---|---|
| M.2 Primary | NVMe PCIe 4.0 | 2280 | PCIe 4.0 NVMe 2280 |
| 2.5″ Secondary | SATA III | Up to 1TB+ | 2.5″ SATA SSD |
Best practice: Use the M.2 slot for your OS and applications (fast PCIe 4.0 drive), and the 2.5″ bay for media libraries or backups (SATA SSD is perfectly adequate for sequential reads).
Power Supply Specifications
The M80q Gen 4 ships with a 120W external PSU, which is plenty for the 13th Gen Core i5/i7 platform. Power consumption is modest, so you won’t have headroom for major external peripherals, but it’s not a limitation for typical usage.
Display Connectivity
Standard configuration includes HDMI and DisplayPort. Some configurations optionally include Thunderbolt 4. If your unit has TB4, you gain the flexibility of a single-cable dock and high-speed data transfers. If not, HDMI + DP still supports dual 4K displays comfortably.
- HDMI 2.1: 4K @ 60Hz or 8K @ 30Hz.
- DisplayPort 1.4: Up to 8K @ 60Hz.
- Thunderbolt 4 (optional): Video + data + power delivery if included.
WiFi & Bluetooth
The M80q Gen 4 comes with Intel WiFi 6 (802.11ax) and Bluetooth 5.2. These are mature, reliable standards suitable for modern office and creative work. No upgrades needed—both are solid performers.
Upgradeability Score
7 out of 10. RAM and storage are easily user-serviceable, giving you flexibility to extend the machine’s lifespan. The CPU is locked, but that’s expected in the Tiny form factor. DDR4-3200 is still relevant for the foreseeable future.
Frequently Asked Questions
Can I Upgrade the M80q Gen 4 to 64GB of RAM?
Yes, absolutely. Install a pair of 32GB DDR4-3200 SO-DIMM modules and you’re at the maximum. Most users will find 32GB more than sufficient for multitasking and memory-intensive applications.
Is DDR4-3200 or DDR4-3600 Better for the M80q Gen 4?
The board is rated for DDR4-3200. While DDR4-3600 might technically work, it could run at reduced speed or cause stability issues. Stick with DDR4-3200 for guaranteed compatibility and stability.
What’s the Difference Between M80q and M90q?
The M90q is the premium tier: it uses DDR5-5200 (vs. DDR4-3200), features Thunderbolt 4 standard, and includes vPro processors. The M80q is the value-oriented option with DDR4, optional TB4, and standard Core processors. Both are excellent machines—choose based on budget and workload requirements.
Does the M80q Gen 4 Have PCIe Gen 5 NVMe Support?
No. The M.2 slot supports PCIe Gen 4.0. PCIe Gen 5 drives will work but will operate at Gen 4 speeds. Gen 4 is perfectly adequate for current workflows.
Will an M80q Gen 4 Handle Video Editing?
Yes, particularly with a DDR4-3200 RAM upgrade to 32GB or 64GB. Pair it with a fast PCIe 4.0 NVMe drive and you’ve got a capable editing workstation. 4K editing is possible, though heavy effects processing may benefit from the DDR5 tier (M90q) if your budget stretches.
Recommended Products
These are the products we recommend based on this guide. All links go to Amazon UK where you can check current prices and availability.
| Product | Why We Recommend It | Amazon UK |
|---|---|---|
| Corsair Vengeance DDR4 SO-DIMM 32GB (2×16GB) 3200MHz | Best overall DDR4 upgrade kit | View on Amazon UK |
| Kingston Fury Impact DDR4 SO-DIMM 32GB (2×16GB) 3200MHz | Reliable alternative with tight latency | View on Amazon UK |
| Corsair Vengeance DDR5 SO-DIMM 32GB (2×16GB) 5600MHz | Top-rated DDR5 kit for gaming & productivity | View on Amazon UK |
| Kingston Fury Impact DDR5 SO-DIMM 32GB (2×16GB) 5600MHz | Excellent DDR5 alternative with XMP support | View on Amazon UK |
| Samsung 990 Pro 2TB NVMe M.2 2280 | Fastest consumer NVMe — ideal for gaming & editing | View on Amazon UK |
| WD Black SN850X 2TB NVMe | Excellent Gen4 speed with heatsink option | View on Amazon UK |
| Crucial P5 Plus 1TB NVMe | Great value Gen4 SSD | View on Amazon UK |
| Kingston NV2 1TB NVMe | Budget-friendly with solid reliability | View on Amazon UK |
Prices and availability may vary. As an Amazon Associate, we earn from qualifying purchases.
