HP Pavilion 15 (2024) Overview
HP’s Pavilion 15 is a versatile 15.6-inch everyday laptop for 2024, available with either Intel or AMD processors depending on configuration. Some variants ship with DDR4-3200 (older stock) while newer models feature DDR5, so verify your specific configuration before purchasing upgrades. The design prioritizes affordability and repairability, with accessible SO-DIMM slots and NVMe bays.
| Component | Specification |
|---|---|
| Processor | Intel Core i7-1355U or AMD Ryzen 7 8840HS |
| RAM Type | DDR4-3200 OR DDR5-5600 (2× SO-DIMM) |
| Max RAM | 32GB (16GB × 2, any variant) |
| Storage | 512GB / 1TB M.2 2280 NVMe Gen3/Gen4 |
| Charger | 45W USB-C (USB Power Delivery) |
| Ports | 2× USB-C 3.2 Gen1, 2× USB-A 3.2, HDMI 2.0, headphone jack |
| Display | 15.6″ FHD (1920×1080), IPS 45% NTSC |
| Weight | 1.65 kg (3.6 lbs) |
RAM Upgrade: Important Configuration Notes
The Pavilion 15 (2024) comes in two memory variants, so verify which type you have before purchasing upgrade modules:
DDR4 variants (older inventory):
- Speed: DDR4-3200
- Max capacity: 32GB (2× 16GB)
- Compatible modules: Any DDR4-3200 or DDR4-3600 SO-DIMM
DDR5 variants (newer 2024 models):
- Speed: DDR5-5600
- Max capacity: 32GB (2× 16GB)
- Compatible modules: Any DDR5-5600 or faster SO-DIMM
To identify your type: Open Settings → System → About. Under Device Specifications, check RAM type. Or run CPU-Z (free tool) and check the Memory tab.
DDR4 upgrade recommendations:
- Crucial CT8G4SFS8213 DDR4-3200 8GB — Budget single upgrade
- Kingston ValueRAM DDR4-3200 16GB — High capacity, good value
DDR5 upgrade recommendations:
- Crucial DDR5-5600 16GB — Excellent speed-to-value ratio
- Kingston FURY Beast DDR5-5600 16GB — Performance-tuned for gaming
Critical note: Mixing DDR4 and DDR5 is impossible — modules are physically keyed differently. Install only the type your laptop has.
Storage Upgrade: M.2 NVMe SSD
The Pavilion 15 (2024) includes one M.2 2280 slot. Older models use Gen3 drives (up to 3500 MB/s), while newer ones support Gen4 (up to 7000 MB/s). Verify your slot speed before buying — check Device Manager under Disk drives or run CrystalDiskInfo (free tool).
Upgrade specifications:
- Form factor: M.2 2280 (standard 42mm length)
- Speed: Gen3 or Gen4 compatible (check your slot)
- Capacity: Up to 2TB practical limit
- Installation time: 10–15 minutes
SSD recommendations (Gen4, universal compatibility):
- Samsung 990 EVO 1TB — Reliable, good speed, affordable
- Kingston NV2 2TB — Excellent capacity for the price
- WD Black SN850X 1TB — Premium performance and build
Charger & Power Compatibility
The Pavilion 15 (2024) uses a 45W USB-C Power Delivery charger. It works with any USB-C PD charger rated 45W or higher.
Factory charger: HP 45W USB-C PD (model varies by region)
Compatible third-party chargers:
- Anker 45W Atom PD Charger — Compact, lightweight, affordable
- Lenovo 45W USB-C Charger — Enterprise-grade reliability
- ASUS 65W USB-C Charger — Extra headroom for future upgrades
Tip: A 65W charger future-proofs your accessory drawer if you ever upgrade to a higher-power laptop.
Ports & Connectivity
The Pavilion 15 (2024) includes:
- 2× USB-C 3.2 Gen1 (5 Gbps, power delivery on main port)
- 2× USB-A 3.2 (5 Gbps, backward compatible)
- HDMI 2.0 (1080p@60Hz, no 4K)
- 3.5mm audio jack (legacy audio support)
Note: USB-C ports are standard USB 3.2, not Thunderbolt. Use USB-C hubs rather than Thunderbolt docks.
Recommended USB-C hub:
- Hama USB-C Multiport Hub — Budget-friendly with HDMI and ethernet
Upgrade Difficulty & Tools
RAM upgrade: Very easy (1/5 difficulty). Bottom panel removal reveals SO-DIMM slots. No screws on the panel itself in many models — it’s held by clips.
SSD upgrade: Easy (2/5 difficulty). One or two screws hold the M.2 module. Clear labeling and spacing make installation straightforward.
Tools needed:
- Philips screwdriver (optional for some panel designs)
- Anti-static wrist strap (recommended, ~£2)
Service manual: HP publishes detailed PSREF sheets (Product Specification Reference). Bottom panel removal is routine maintenance and voids no warranty.
Recommended Upgrade Package
- For DDR4 models: Kingston ValueRAM DDR4-3200 16GB — Double capacity upgrade
- For DDR5 models: Kingston FURY Beast DDR5-5600 16GB — Performance RAM
- SSD upgrade: Samsung 990 EVO 1TB — Fast, reliable, good value
- Travel charger: Anker 45W Atom PD — Backup or travel power
